Part #: Barix Exstreamer SoundScape
Barix Part #: 2015.9181
The Exstreamer SoundScape is an audio player that supports playback of Playlists, Adverts and live Streams. Audio content is scheduled from the SoundScape Portal - a central cloud-based management platform that is also used to monitor and configure the player devices. This product is designed for Business Music applications that demand high flexibility and reliability in scheduling, monitoring and reporting of audio playback and is especially suitable for Content Providers who manage audio content distribution for clients worldwide.
MP3 and AAC+ decoding
Plays Adverts, Playlists and HTTP Streams
Stereo Line Level Output
Internal microSD storage capability
Embedded Real Time Clock
Local web UI
Display and Keypad
Serial and USB 2.0 interfaces
Low Power consumption
TECHNICAL SPECIFICATIONS
Electrical
Power Supply 5VDC, 2 Watt max.
Standard ‘Micro-B’ USB connector
Ethernet
10/100Mbps Auto-negotiation, Auto MDI-X
RJ-45 connector with integrated Link/Activity LED
Protocols: TCP/IP, FTP, HTTP, DHCP
Web User Interface for remote control, status and troubleshooting
Analog Output
Line level output, 40..60 Ohm impedance on RCA and 1/8” headphone jack
Output level software controllable
Full scale output voltage: 5.6 dBu, 4 Vpp into 600 Ohm load
Frequency response (-3dB) 20Hz...20kHz *
Signal to Noise Ratio -92 dB *
Total harmonic distortion (THD) <0.01% *
Dynamic range 92dB *
Stereo crosstalk -91dB @ 1kHz *
RS-232 Interface
Male 9-pin Sub-D connector
115’200 Baud asynchronous
5 VDC supply output for external device (100 mA max.)
AUDIO FORMATS
MP3 codec
MP3 files (MPEG version 1, 2 and 2.5 layer III)
CBR, VBR and ABR
8 to 320 kbps
8 to 48 kHz sample frequency
AAC and AAC+ codecs
AAC, MP4 and M4A audio file extensions
Main Profile, AAC-LC, AAC-HE v1 and v2
CBR and VBR
Up to 576 kbps
DRC (Dynamic Range Control)
HTTP Streams
ICEcast and SHOUTcast streams
Miscellaneous
Retro-illuminated display with 2 lines/16 chars and keypad with 5 buttons
RESET button for reboot and reset factory defaults
Mechanical
Aluminum case, 250g
Rack and wall mountable using accessories
Dimensions (W x H x D)
W x H x D: 108x38x78.7mm (4.25x1.5x3.1 inch)
Declarations of conformity
RoHS, FCC, CE, C-Tick
MTBF
(Calculated acc. MIL217F at 25°C environment ground fix)
min. 500’000h
* using MP3 @48kHz sample rate, 320 kbps
